Conductivity/tds Combined Meter
A TDS meter is used to indicate the total dissolved solids (TDS) of the solution i.e.the concentration of dissolved solid particles. Dissolved ionized solids such as salts & minerals increase the electrical conductivity (EC) of the solution can be used to measure the TDS.
| Specification | Details |
|---|---|
| Type | MICROPROCESSOR BASED |
| Function | Display TDS / ES / TEMPERATURE SIMULTANEOUSLY |
| TDS Range | 0 to 1000 ppt Auto ranging |
| EC Range | 0 to 1000 ms Auto ranging |
| Temp | 0 to 100° C |
| Resolution | TDS 0.1 ppm EC 0.1 µ mhos Temp 0.1 °C |
| Accuracy | 0.5% of range |
| Cell Constant | Adjustable |
| Display | 16×2 Alphanumeric |
| Measuring Cell | Platinum DIP Type |
| Temperature Compensation | Manual / Automatic |
| Dimensions | 275 x 187 x 94 mm (Approx) |
| Weight | 1 kg (Approx) |
| Power Supply | 230 V ± 10 V AC, 50Hz |
| Accessories | Conductivity Cell Cell Stand Temp. Probe Operating Manual |
TDS/EC/TEMP with Auto Temperature Compensation,Memory Storage Of 1000 Samples With Date & Time.Pc Interface
NEW GENERATION TDS/EC/TEMP with Auto Temperature Compensation & Android Interface. Unlimited Memory Storage With Date And Time.
